- Input Supply :- 88 VAC – 275 VAC
- Line Frequency 50Hz/60 Hz
- Max. Flow :- 45 Liters
- Power Consumption :- 300 VA Max.
- Input Fuse :- 3.15A T
- Gas Type Co2 liquified
- Inlet Pressure :- 70 bar max.
- Dimensions (in mm) :- 420(L) x 340(W) x 160(H)
- Weight :- 7 Kg (max.)
- Basic construction :- In accordance with IEC 60601-1 and IEC 60601-1-2
- Protection Class :- 1
- Unit type CF
- Electrical potential balancing :- Indicated by symbol
- Temperature range: +10° C to +40° C
- Relative humidity: 30% to 75% non-condensing
- Advanced micro controller based technology.
- Works with wide input range
- No need of stabilizer due to wide operating range design
- Independent display for set pressure and actual pressure. In bar graph and digital display
- Independent display for set flow and actual flow in bar graph and digital display
- Flow settable 0.1 to 45 LPM
- Pressure settable 1 to 30mmHg.
- 9 User program memories for different surgeries as per Surgeon’s preference.
- Ideal for all Laparoscopic surgeries including pediatric surgeries
- Realtime pressure and flow control.
- Power up selftest to ensure, unit healthiness.
- Easy flow “start/stop” control
- Separate key for volume reset
- Ergonomic design
- Paediatric surgeries
- Bariatric surgeries
- Lap/Gynace surgeries
